MS75021-1 -- 12 Pin 24V Amphenol Brass Electrical Socket for Military Vehicles including HUMVEE

Regular price $48.00 Sale price $38.25

Made in USA - NEW!  Amphenol Trailer mounted receptacle. Complete with back shell and grommet as shown. Solder cups for wire connection. p/n MS75021-1, alternate numbers 2HA24, 7525173, 60-036028-51P. NSN 5935008463883.

WIRING INSTRUCTIONS:


Standard Military vehicle wiring information (letters are marked next to connector contacts)

A, C, H - blackout tail lights and blackout clearance lights (all three pins are electrically connected together within vehicle's wiring harness)

B - brake light and left turn signal light

D - ground

E - tail lights / clearance lights

F - blackout brake light

J - brake light and right turn signal light

K - auxillary power feed used on semi tractor only

L, M, N - not used
